Lifecycle Status

ACTIVE (Last Updated: 2 weeks ago)

Factory Lead Time

24 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

Module

Operating Temperature

-40°C~85°C

Packaging

Tray

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

11

ECCN Code

5A992.C

Voltage - Supply

1.8V~3.6V

Terminal Position

UNSPECIFIED

Terminal Form

NO LEAD

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Supply Voltage

3.3V

Terminal Pitch

1.27mm

Frequency

868MHz

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

SPSGRF

JESD-30 Code

R-XXMA-N11

Data Rate

500kbps

Utilized IC / Part

SPIRIT1

Telecom IC Type

TELECOM CIRCUIT

Power - Output

11.6dBm

RF Family/Standard

General ISM < 1GHz

Antenna Type

Integrated, Chip

Serial Interfaces

SPI

Current - Receiving

10mA

Current - Transmitting

9mA~22mA

Modulation

2-FSK, ASK, GFSK, GMSK, MSK, OOK

Sensitivity (dBm)

-118 dBm

Number of GPIO

4

Height

2.2mm

Length

13.5mm

Width

11.5mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
