Mount

Through Hole

Mounting Type

Through Hole, Right Angle

Actuator Material

Brass, Chrome Plated

Center Contact Plating

GOLD

End Contact Plating

GOLD

ElectricalLife

60,000 Cycles

Insulation Materials

THERMOPLASTIC

Operating Temperature

-30°C~85°C

Packaging

Bulk

Series

WT

Published

2001

Part Status

Active

Termination

PC Pin

Voltage - Rated DC

28V

Current Rating (Amps)

0.5VA AC/DC

Reach Compliance Code

unknown

Termination Style

PC Pin

Voltage - Rated AC

28V

Body Length or Diameter

13.5128mm

Body Breadth

11.7348 mm

Actuator Type

Standard Round

Circuit

DPDT

Switch Function

On-Off-Mom

Contact Resistance

0.01mOhm

Insulation Resistance

1000000000Ohm

Sealing

EPOXY

Dielectric Withstanding Voltage

1400VAC V

Illumination

Non-Illuminated

Switch Type

TOGGLE SWITCH

Bushing Thread

Unthreaded

Contact Timing

MAKE-BEFORE-BREAK

PCB Hole Count

8

Contact Function

ON-OFF-(ON)

Bushing Length

0.25 inch

Contact (DC) Max Power Rating R Load

0.5VA@28VDC

Actuator Finish

BRIGHT CHROME

Body Height

16.51mm

Length - Termination

0.13 inch

Actuator Length

7.60mm

RoHS Status

RoHS Compliant

Lead Free

Lead Free
