Lifecycle Status

ACTIVE (Last Updated: 7 months ago)

Factory Lead Time

20 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

4-XDFN Exposed Pad

Number of Pins

4

Operating Temperature

-40°C~125°C TJ

Packaging

Cut Tape (CT)

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

4

ECCN Code

EAR99

Terminal Position

DUAL

Number of Functions

1

Terminal Pitch

0.65mm

Base Part Number

LD39020

Voltage - Input (Max)

5.5V

Output Voltage

3.3V

Output Type

Fixed

Max Output Current

200mA

Output Configuration

Positive

Quiescent Current

40μA

Control Features

Enable

Accuracy

2 %

Output Voltage 1

3.3V

Number of Regulators

1

Min Input Voltage

1.5V

Protection Features

Over Current, Over Temperature, Soft Start

Current - Quiescent (Iq)

40μA

Voltage Dropout (Max)

0.35V @ 200mA

PSRR

80dB ~ 55dB (1kHz ~ 100kHz)

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
