Mount

Surface Mount

Package / Case

492-BBGA

Number of Pins

492

Operating Temperature

0°C~70°C TA

Packaging

Tray

Published

2004

JESD-609 Code

e1

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

4 (72 Hours)

Number of Terminations

492

ECCN Code

3A991.A.2

Terminal Finish

TIN SILVER COPPER

HTS Code

8542.31.00.01

Terminal Position

BOTTOM

Terminal Form

BALL

Peak Reflow Temperature (Cel)

245

Supply Voltage

1.3V

Terminal Pitch

1.27mm

Frequency

266MHz

Time@Peak Reflow Temperature-Max (s)

40

Pin Count

492

Voltage

1.3V

Speed

533 MHz

uPs/uCs/Peripheral ICs Type

MICROPROCESSOR, RISC

Core Processor

Xscale

Bit Size

32

Address Bus Width

32

Boundary Scan

YES

Low Power Mode

NO

External Data Bus Width

32

Format

FIXED POINT

Integrated Cache

YES

Voltage - I/O

3.3V

Ethernet

10/100Mbps (2)

Number of Cores/Bus Width

1 Core 32-Bit

Graphics Acceleration

No

RAM Controllers

SDRAM

USB

USB 1.1 (1)

Additional Interfaces

HSS, MII, PCI, UART, UTOPIA 2

Co-Processors/DSP

Communications; Network Processor Engine, Math Engine; Multiply-Accumulate

Security Features

Cryptography

Height Seated (Max)

2.59mm

Length

35mm

RoHS Status

RoHS Compliant

Lead Free

Lead Free
