Factory Lead Time

4 Weeks

Contact Plating

Gold

Mount

Panel

Mounting Type

Panel Mount

Package / Case

Metal

Material

Liquid Crystal Polymer, Polymer

Dielectric Material

Polybutylene Terephthalate (PBT), Polyester, Glass Filled

Housing Material

PBT

Shell Material, Finish

Steel

Contact Finish Mating

NOT SPECIFIED

Contact Materials

Copper Alloy

Voltage Rated

32V

Packaging

Bulk

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

IDC, Ribbon Cable

Connector Type

Receptacle, Female Sockets

Number of Positions

37

Max Operating Temperature

125°C

Min Operating Temperature

-55°C

Number of Rows

2

Gender

Receptacle

MIL Conformance

NO

DIN Conformance

YES

IEC Conformance

YES

Filter Feature

NO

Contact Type

Signal

Mixed Contacts

NO

Option

GENERAL PURPOSE

Pitch

2.77mm

Total Number of Contacts

37

Orientation

Right Angle

Depth

18.2mm

Current Rating

2A

Shell Finish

TIN

Reference Standard

UL, CSA

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Body Breadth

0.509 inch

UL Flammability Code

94V-0

Empty Shell

NO

Rated Current (Signal)

1A

Insulation Resistance

1000000000Ohm

Flange Feature

Housing/Shell (Unthreaded)

Body/Shell Style

PLUG

Dielectric Withstanding Voltage

1000VAC V

Connector Style

D-Sub

Shell Size, Connector Layout

4 DC C

Contact Design

PREASSEM CONN

Features

Feed Through

Length

69.4mm

Width

12.55mm

Material Flammability Rating

UL94 V-0

RoHS Status

ROHS3 Compliant
