Factory Lead Time

10 Weeks

Contact Plating

Gold

Mount

Panel

Mounting Type

Panel Mount

Dielectric Material

Polybutylene Terephthalate (PBT), Polyester, Glass Filled

Housing Material

Polybutylene

Body Material

Metal

Shell Material, Finish

Steel

Contact Finish Mating

NOT SPECIFIED

Contact Materials

Copper Alloy

Packaging

Bulk

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

37

Termination

IDC, Ribbon Cable

ECCN Code

EAR99

Connector Type

Plug, Male Pins

Max Operating Temperature

125°C

Min Operating Temperature

-55°C

Number of Rows

2

Gender

Male

HTS Code

8536.69.40.30

MIL Conformance

NO

DIN Conformance

YES

IEC Conformance

YES

Filter Feature

NO

Contact Type

Signal

Mixed Contacts

NO

Option

GENERAL PURPOSE

Current Rating (Amps)

2A

Total Number of Contacts

37

Orientation

Right Angle

Depth

12.55mm

Shell Finish

TIN

Reference Standard

UL, CSA

Lead Pitch

2.77mm

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Body Breadth

0.509 inch

UL Flammability Code

94V-0

Empty Shell

NO

Flange Feature

Housing/Shell (Unthreaded)

Body/Shell Style

RECEPTACLE

Connector Style

D-Sub

Number of Ports

1

Shell Size, Connector Layout

4 DC C

Contact Design

PREASSEM CONN

Features

Feed Through, Grounding Indents

Length

69.4mm

Material Flammability Rating

UL94 V-0

REACH SVHC

No SVHC

RoHS Status

ROHS3 Compliant
