Mount

PCB, Surface Mount

Mounting Type

Surface Mount

Package / Case

SMD/SMT

Operating Temperature

-40°C~125°C

Packaging

Tape & Reel (TR)

Series

FRB

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Gull Wing

ECCN Code

EAR99

Type

Glass Body

Terminal Finish

Matte Tin (Sn)

HTS Code

8536.50.70.00

Capacitance

0.3pF

Termination Style

Gull Wing

Body Length or Diameter

13.94mm

Circuit

SPST-NO

Contact Current(DC)-Max

0.5A

Sealing

HERMETICALLY SEALED

Contact Voltage(DC)-Max

200V

Throw Configuration

SPST

Operate Time

0.5ms

Release Time

0.2ms

Power - Rated

10VA

Size - Body

0.549Lx0.100W x 0.090 H 13.94mmx2.54mmx2.29mm

Current - Switching

500mA AC/DC

Operate Range

15 ~ 25AT

Current - Carry

1.5A AC/DC

Voltage - Switching AC

200V

Pull-in Value-Max

25 AT

Pull-in Value-Min

15 AT

Drop-out Value-Min

5 AT

Body Height

2.9mm

Length - Overall

0.770 19.56mm

Height Above Board

0.114 2.90mm

RoHS Status

RoHS Compliant
