Mounting Type

Surface Mount

Package / Case

28-SOIC (0.295, 7.50mm Width), 12 Leads

Surface Mount

YES

Number of Pins

12

Operating Temperature

-40°C~85°C

Packaging

Tube

JESD-609 Code

e4

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

12

ECCN Code

EAR99

Type

General Purpose

Terminal Finish

Nickel/Palladium/Gold (Ni/Pd/Au)

Voltage - Supply

3V~5.5V

Terminal Position

DUAL

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

260

Number of Functions

2

Supply Voltage

5V

Base Part Number

ISO150

Pin Count

12

Voltage - Isolation

1500Vrms

Number of Channels

2

Operating Supply Current

14mA

Propagation Delay

27 ns

Turn On Delay Time

27 ns

Data Rate

80MBd

Rise / Fall Time (Typ)

9ns 9ns

Channel Type

Bidirectional

Propagation Delay tpLH / tpHL (Max)

40ns, 40ns

Common Mode Transient Immunity (Min)

1.6kV/μs (Typ)

Inputs - Side 1/Side 2

2/2

Isolated Power

No

Pulse Width Distortion (Max)

6ns

Length

17.9mm

REACH SVHC

No SVHC

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
