Factory Lead Time

20 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

SMD/SMT

CoilResistance

650Ohm

ElectricalLife

1000000000 Cycle(s)

Operating Temperature

-20°C~85°C

Packaging

Bulk

Series

9200

Published

2006

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

2 (1 Year)

Number of Terminations

6

Termination

Gull Wing

ECCN Code

EAR99

Terminal Finish

Gold (Au)

Reach Compliance Code

unknown

Reference Standard

UL

Termination Style

Gull Wing

Approval Agency

UL

Body Length or Diameter

17.78mm

Contact Resistance

200mOhm

Insulation Resistance

1000000000000Ohm

Contact Current(DC)-Max

0.5A

Contact Voltage(DC)-Max

200V

Throw Configuration

SPST

Contact Form

SPST-NO (1 Form A)

Relay Type

RF

Contact Current(AC)-Max

0.5A

Contact (AC) Max Rating R Load

0.5A@200VAC

Operate Time

0.4ms

Coil Voltage

12VDC

Coil Type

Non Latching

Switching Voltage

200VAC 200VDC -Max

Coil Current

18.5mA

Release Time

0.1ms

Contact (DC) Max Rating R Load

0.5A@200VDC

Must Operate Voltage

9VDC

Must Release Voltage

1VDC

Contact Voltage(AC)-Max

200V

Contact/Output Supply Type

AC/DC

Relay Action

LATCHED

Coil Voltage (DC)

12V

Coil/Input Supply Type

DC

Dielectric Strength Between Open Contacts

300 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1500 Vrms

Switching Current

500mA

Contact (DC) Max Power Rating R Load

10W@200VDC

Features

Sealed - Hermetically

Body Height

4.83mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
