Factory Lead Time

20 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

SMD/SMT

CoilResistance

825Ohm

Operating Temperature

-20°C~85°C

Packaging

Bulk

Series

9400

Published

2006

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

2 (1 Year)

Number of Terminations

6

Termination

Gull Wing

ECCN Code

EAR99

Terminal Finish

Gold (Au)

Termination Style

Gull Wing

Physical Dimension

14mm x 5.71mm x 5.72mm

Contact Resistance

150mOhm

Insulation Resistance

1000000000000Ohm

Contact Current(DC)-Max

0.5A

Sealing

HERMETICAL

Contact Voltage(DC)-Max

200V

Throw Configuration

SPST

Contact Form

SPST-NO (1 Form A)

Rise Time

400μs

Relay Type

RF

Contact Current(AC)-Max

0.5A

Contact (AC) Max Rating R Load

0.5A@200VAC

Operate Time

0.4ms

Coil Voltage

12VDC

Coil Type

Non Latching

Switching Voltage

200VAC 200VDC -Max

Coil Current

14.5mA

Release Time

0.2ms

Contact (DC) Max Rating R Load

0.5A@200VDC

Must Operate Voltage

9VDC

Must Release Voltage

1VDC

Contact Voltage(AC)-Max

200V

Contact/Output Supply Type

AC/DC

Relay Action

LATCHED

Coil Voltage (DC)

12V

Coil/Input Supply Type

DC

Dielectric Strength Between Open Contacts

300 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1500 Vrms

Switching Current

500mA

Contact (DC) Max Power Rating R Load

10W@200VDC

Height

5.72mm

Length

17.8mm

Width

5.71mm

REACH SVHC

No SVHC

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
