Factory Lead Time

22 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

SIP

CoilResistance

350Ohm

ElectricalLife

1000000000 Cycle(s)

Operating Temperature

-20°C~85°C

Packaging

Tube

Series

9000

Published

2011

JESD-609 Code

e3

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

6

Termination

PC Pin

ECCN Code

EAR99

Terminal Finish

Matte Tin (Sn)

Reference Standard

CSA; UL

Termination Style

PC Pin

Approval Agency

CSA, UL

Body Length or Diameter

19.8mm

Contact Resistance

200mOhm

Insulation Resistance

1000000000000Ohm

Sealing

HERMETICAL

Contact Voltage(DC)-Max

200V

Throw Configuration

SPST

Contact Form

SPST-NO (1 Form A)

Relay Type

RF

Contact (AC) Max Rating R Load

0.5A@200VAC

Operate Time

0.35ms

Coil Voltage

5VDC

Coil Type

Non Latching

Switching Voltage

200VAC 200VDC -Max

Coil Current

14.3mA

Release Time

0.1ms

Contact (DC) Max Rating R Load

0.5A@200VDC

Must Operate Voltage

3.75VDC

Contact Rating (Current)

500mA

Must Release Voltage

0.4VDC

Contact Voltage(AC)-Max

200V

Contact/Output Supply Type

AC/DC

Relay Action

LATCHED

Coil Voltage (DC)

5V

Coil/Input Supply Type

DC

PCB Hole Count

6

Dielectric Strength Between Open Contacts

300 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1500 Vrms

Contact (DC) Max Power Rating R Load

10W@200VDC

Features

Diode, Magnetic Shield

Body Height

8.1mm

Length - Termination

0.0034 inch

RoHS Status

ROHS3 Compliant
