Factory Lead Time

20 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

SMD/SMT

CoilResistance

150Ohm

Coil Voltage AC

5V

Contact Materials

Ruthenium

ElectricalLife

1000000000 Cycle(s)

Operating Temperature

-20°C~85°C

Packaging

Tube

Series

9200

Published

2006

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

2 (1 Year)

Number of Terminations

6

ECCN Code

EAR99

Terminal Finish

Gold (Au)

Reach Compliance Code

unknown

Reference Standard

UL

Termination Style

J Lead

Contact Resistance

150mOhm

Insulation Resistance

1000000000000Ohm

Contact Current(DC)-Max

0.5A

Contact Voltage(DC)-Max

200V

Throw Configuration

SPST

Contact Form

SPST-NO (1 Form A)

Rise Time

400μs

Relay Type

RF

Contact Current(AC)-Max

0.5A

Contact (AC) Max Rating R Load

0.5A@200VAC

Operate Time

0.4ms

Coil Voltage

5VDC

Coil Type

Non Latching

Switching Voltage

200VAC 200VDC -Max

Coil Current

33.3mA

Release Time

0.1ms

Contact (DC) Max Rating R Load

0.5A@200VDC

Must Operate Voltage

3.75VDC

Must Release Voltage

0.4VDC

Contact Voltage(AC)-Max

200V

Contact/Output Supply Type

AC/DC

Relay Action

LATCHED

Coil Voltage (DC)

5V

Coil/Input Supply Type

DC

Dielectric Strength Between Open Contacts

300 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1500 Vrms

Switching Current

500mA

Contact (DC) Max Power Rating R Load

10W@200VDC

Features

Sealed - Hermetically

Height

4.83mm

Length

17.8mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
