Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

2-SMD, J-Lead

Number of Elements

1

Voltage - Rated (AC)

50V

Voltage - Rated (DC)

50V

Operating Temperature

-55°C~125°C

Packaging

Tape & Reel (TR)

Series

ICP-S

Size / Dimension

0.118Lx0.098W x 0.079 H 3.00mmx2.50mmx2.00mm

JESD-609 Code

e2

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

Resistance

61mOhm

Terminal Finish

TIN COPPER

Additional Feature

UL RECOGNIZED

HTS Code

8541.30.00.80

Current Rating (Amps)

1A

Terminal Position

DUAL

Terminal Form

C BEND

Peak Reflow Temperature (Cel)

260

Reach Compliance Code

unknown

Time@Peak Reflow Temperature-Max (s)

10

JESD-30 Code

R-PDSO-C2

Qualification Status

Not Qualified

Configuration

SINGLE

Response Time

Fast Blow

Fuse Type

Board Mount (Cartridge Style Excluded)

DC Cold Resistance

0.061Ohm

Trigger Device Type

SILICON SURGE PROTECTOR

Height

2mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
