Factory Lead Time

15 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

SMD/SMT

Number of Pins

8

CoilResistance

110Ohm

Contact Materials

Ruthenium

ElectricalLife

100000000 Cycle(s)

Operating Temperature

-20°C~85°C

Packaging

Tube

Series

9800

Published

2010

JESD-609 Code

e4

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

2 (1 Year)

Number of Terminations

8

ECCN Code

EAR99

Terminal Finish

Gold (Au)

Additional Feature

SHIELDED

Packing Method

TAPE AND REEL

Termination Style

Axial

Lead Pitch

1.02mm

Physical Dimension

10.16mm x 4.95mm x 4.95mm

Contact Resistance

150mOhm

Insulation Resistance

1GOhm

Row Spacing

12.06 mm

Contact Current(DC)-Max

0.1A

Sealing

HERMETICALLY SEALED

Contact Voltage(DC)-Max

30V

Throw Configuration

SPDT

Contact Form

SPDT (1 Form C)

Rise Time

260μs

Relay Type

RF

Contact Current(AC)-Max

0.1A

Contact (AC) Max Rating R Load

.1A@30VAC

Operate Time

1ms

Coil Voltage

5VDC

Coil Type

Non Latching

Switching Voltage

30VAC 30VDC -Max

Coil Current

45.5mA

Release Time

1 ms

Contact (DC) Max Rating R Load

.1A@30VDC

Must Operate Voltage

3.8VDC

Coil Power

225mW

Must Release Voltage

0.4VDC

Contact Voltage(AC)-Max

30V

Contact/Output Supply Type

AC/DC

Relay Action

MOMENTARY

Coil Voltage (DC)

5V

Coil/Input Supply Type

DC

Dielectric Strength Between Open Contacts

200 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1000 Vrms

Switching Current

100mA

Features

Magnetic Shield

Height

4.95mm

Length

9.52mm

Width

10.16mm

REACH SVHC

Unknown

RoHS Status

RoHS Compliant

Lead Free

Lead Free
