Mount

Through Hole

Mounting Type

Through Hole

CoilResistance

250Ohm

ElectricalLife

1000000000 Cycle(s)

Operating Temperature

-20°C~85°C

Packaging

Tube

Series

9200

Published

2006

JESD-609 Code

e4

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

2 (1 Year)

Number of Terminations

6

Termination

PC Pin

Terminal Finish

Gold (Au)

Packing Method

TAPE AND REEL

Reach Compliance Code

unknown

Reference Standard

UL

Termination Style

PC Pin

Body Length or Diameter

20.32mm

Body Breadth

6.1 mm

Physical Dimension

20.32mm x 6.1mm x 4.57mm

Insulation Resistance

1000000000000Ohm

Contact Voltage(DC)-Max

200V

Throw Configuration

SPST

Contact Form

SPST-NO (1 Form A)

Relay Type

Reed

Operate Time

0.4ms

Coil Voltage

5VDC

Coil Type

Non Latching

Switching Voltage

200VAC 200VDC -Max

Coil Current

20mA

Release Time

0.1ms

Contact (DC) Max Rating R Load

10A@200VDC

Must Operate Voltage

3.75VDC

Contact Rating (Current)

500mA

Must Release Voltage

0.4VDC

Contact/Output Supply Type

DC

Relay Action

LATCHED

Coil Voltage (DC)

5V

Coil/Input Supply Type

DC

Seal Rating

Sealed - Hermetically

Dielectric Strength Between Open Contacts

300 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1500 Vrms

Contact (DC) Max Power Rating R Load

10W@200VDC

Body Height

4.57mm

RoHS Status

RoHS Compliant
