Factory Lead Time

20 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

SIP

Number of Pins

6

CoilResistance

750Ohm

Coil Voltage AC

12V

Operating Temperature

-20°C~85°C

Packaging

Tube

Series

9092

Published

2005

JESD-609 Code

e3

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

6

Termination

PC Pin

ECCN Code

EAR99

Terminal Finish

Matte Tin (Sn)

Termination Style

PC Pin

Physical Dimension

15.24mm x 3.81mm x 8.89mm

Contact Resistance

140mOhm

Insulation Resistance

1000000000000Ohm

Contact Current(DC)-Max

0.5A

Sealing

HERMETICAL

Contact Voltage(DC)-Max

200V

Throw Configuration

DPST

Contact Form

DPST-NO (2 Form A)

Rise Time

750μs

Relay Type

Reed

Contact Current(AC)-Max

0.5A

Contact (AC) Max Rating R Load

0.5A@200VAC

Operate Time

0.75ms

Coil Voltage

12VDC

Coil Type

Non Latching

Switching Voltage

200VAC 200VDC -Max

Coil Current

16mA

Release Time

0.5ms

Contact (DC) Max Rating R Load

0.5A@200VDC

Must Operate Voltage

9VDC

Must Release Voltage

1VDC

Contact Voltage(AC)-Max

200V

Contact/Output Supply Type

AC/DC

Relay Action

LATCHED

Coil Voltage (DC)

12V

Coil/Input Supply Type

DC

PCB Hole Count

6

Dielectric Strength Between Open Contacts

200 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1500 Vrms

Switching Current

500mA

Contact (DC) Max Power Rating R Load

10W@200VDC

Features

EMI Shielded

Height

8.89mm

Length

15.2mm

Width

3.81mm

RoHS Status

RoHS Compliant

Lead Free

Lead Free
