Factory Lead Time

22 Weeks

Mount

Through Hole

Mounting Type

Through Hole

CoilResistance

500Ohm

Operating Temperature

-20°C~125°C

Packaging

Tube

Series

2370

Published

1995

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

8

Termination

PC Pin

ECCN Code

EAR99

HTS Code

8536.49.00.50

Termination Style

PC Pin

Body Length or Diameter

20.57mm

Body Breadth

5.33 mm

Physical Dimension

20.57mm x 5.33mm x 9.7mm

Insulation Resistance

1000000000000Ohm

Contact Current(DC)-Max

0.5A

Contact Voltage(DC)-Max

200V

Throw Configuration

3PST

Contact Form

3PST-NO (3 Form A)

Relay Type

Reed

Contact Current(AC)-Max

0.5A

Contact (AC) Max Rating R Load

0.5A@200VAC

Operate Time

0.5ms

Coil Voltage

12VDC

Coil Type

Non Latching

Switching Voltage

200VAC 200VDC -Max

Coil Current

24mA

Release Time

0.15ms

Contact (DC) Max Rating R Load

0.5A@200VDC

Must Operate Voltage

6.7VDC

Must Release Voltage

1VDC

Contact Voltage(AC)-Max

200V

Contact/Output Supply Type

AC/DC

Relay Action

LATCHED

Coil Voltage (DC)

12V

Coil/Input Supply Type

DC

PCB Hole Count

8

Seal Rating

Sealed - Hermetically

Dielectric Strength Between Open Contacts

250 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1000 Vrms

Switching Current

500mA

Contact (DC) Max Power Rating R Load

10W@200VDC

Body Height

9.7mm

Length - Termination

0.0034 inch

REACH SVHC

Unknown

RoHS Status

ROHS3 Compliant
