Factory Lead Time

20 Weeks

Mount

Through Hole

Mounting Type

Through Hole

CoilResistance

350Ohm

Contact Materials

Ruthenium

Operating Temperature

-20°C~85°C

Packaging

Tube

Series

3600

Published

2012

JESD-609 Code

e3

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

10

Termination

PC Pin

Terminal Finish

Matte Tin (Sn)

Termination Style

PC Pin

Body Length or Diameter

30.48mm

Body Breadth

16.76 mm

Physical Dimension

30.48mm x 16.76mm x 12.06mm

Insulation Resistance

1000000000000Ohm

Sealing

HERMETICAL

Contact Voltage(DC)-Max

150V

Throw Configuration

3PST

Contact Form

3PST-NO (3 Form A)

Relay Type

Reed

Contact (AC) Max Rating R Load

0.25A@150VAC

Operate Time

0.75ms

Coil Voltage

5VDC

Coil Type

Non Latching

Switching Voltage

150VAC 150VDC -Max

Coil Current

14.3mA

Release Time

0.1ms

Contact (DC) Max Rating R Load

0.25A@150VDC

Must Operate Voltage

3.8VDC

Contact Rating (Current)

250mA

Must Release Voltage

0.4VDC

Contact Voltage(AC)-Max

150V

Contact/Output Supply Type

AC/DC

Relay Action

LATCHED

Coil Voltage (DC)

5V

Coil/Input Supply Type

DC

PCB Hole Count

10

Dielectric Strength Between Open Contacts

250 Vrms

Input Switching Control Type

Random

Dielectric Strength Between Coil and Contacts

1500 Vrms

Body Height

12.06mm

Length - Termination

0.0029 inch

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
