Factory Lead Time

22 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

CoilResistance

350Ohm

Operating Temperature

-20°C~85°C

Packaging

Bulk

Series

9300

Published

2006

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

2 (1 Year)

Number of Terminations

4

Termination

Gull Wing

ECCN Code

EAR99

Terminal Finish

Gold (Au)

Current Rating

1.5A

Termination Style

Gull Wing

Number of Contacts

1

Body Breadth

6.09 mm

Contact Resistance

200mOhm

Contact Current(DC)-Max

0.5A

Sealing

HERMETICAL

Contact Voltage(DC)-Max

200V

Throw Configuration

SPST

Contact Form

SPST-NO (1 Form A)

Relay Type

Reed

Contact Current(AC)-Max

0.5A

Contact (AC) Max Rating R Load

0.5A@200VAC

Operate Time

0.4ms

Coil Voltage

5VDC

Coil Type

Non Latching

Switching Voltage

200VAC 200VDC -Max

Coil Current

14.3mA

Release Time

0.1ms

Contact (DC) Max Rating R Load

0.5A@200VDC

Must Operate Voltage

3.75VDC

Must Release Voltage

0.4VDC

Contact Voltage(AC)-Max

200V

Contact/Output Supply Type

AC/DC

Relay Action

LATCHED

Coil Voltage (DC)

5V

Coil/Input Supply Type

DC

Dielectric Strength Between Open Contacts

500 Vrms

Input Switching Control Type

Random

Switching Current

500mA

Height

6.86mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
