Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

24-PowerSOP

Number of Pins

24

Operating Temperature

-25°C~85°C

Packaging

Tube

Series

Apex Precision Power®

Published

2006

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

24

ECCN Code

EAR99

Terminal Position

DUAL

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

2

Supply Voltage

150V

Terminal Pitch

1mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

PA243

Pin Count

24

Qualification Status

Not Qualified

Number of Circuits

2

Operating Supply Current

2.2mA

Slew Rate

30V/μs

Amplifier Type

Power

Common Mode Rejection Ratio

94 dB

Current - Input Bias

50pA

Voltage - Supply, Single/Dual (±)

100V~350V ±50V~175V

Output Current per Channel

120mA

Input Offset Voltage (Vos)

25mV

Gain Bandwidth Product

3MHz

Neg Supply Voltage-Nom (Vsup)

-150V

Unity Gain BW-Nom

3000 kHz

Supply Voltage Limit-Max

175V

Neg Supply Voltage-Max (Vsup)

-175V

Length

15.9mm

Height Seated (Max)

3.6mm

RoHS Status

RoHS Compliant
