Factory Lead Time

13 Weeks

Mounting Type

Surface Mount

Package / Case

Die

Surface Mount

YES

Operating Temperature

0°C~70°C TA

Published

1995

JESD-609 Code

e0

Pbfree Code

no

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

14

ECCN Code

EAR99

Terminal Finish

TIN LEAD

Additional Feature

ALSO OPERATE WITH 10V TO 30V SINGLE SUPPLY

Terminal Position

UPPER

Terminal Form

NO LEAD

Peak Reflow Temperature (Cel)

240

Number of Functions

2

Supply Voltage

15V

Reach Compliance Code

not_compliant

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Pin Count

14

JESD-30 Code

R-XUUC-N

Qualification Status

Not Qualified

Number of Channels

1

Number of Circuits

2

Voltage - Supply, Single/Dual (±)

10V~30V ±4.5V~20V

Neg Supply Voltage-Nom (Vsup)

-15V

On-State Resistance (Max)

35Ohm

Multiplexer/Demultiplexer Circuit

2:1

Off-state Isolation-Nom

72 dB

Current - Leakage (IS(off)) (Max)

500pA

Channel Capacitance (CS(off), CD(off))

12pF 12pF

On-state Resistance Match-Nom

0.5Ohm

Switch Circuit

SPDT

Switch Time (Ton, Toff) (Max)

150ns, 100ns

Charge Injection

10pC

Channel-to-Channel Matching (ΔRon)

500m Ω

Crosstalk

-90dB @ 1MHz

Switch-on Time-Max

150ns

Switch-off Time-Max

100ns

RoHS Status

Non-RoHS Compliant
