Mounting Type

Surface Mount

Package / Case

Die

Surface Mount

YES

Operating Temperature

0°C~70°C

Published

1995

JESD-609 Code

e0

Pbfree Code

no

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

15

ECCN Code

EAR99

Terminal Finish

Tin/Lead (Sn/Pb)

Additional Feature

ALSO OPERATES WITH 5 TO 15 SINGLE SUPPLY

Terminal Position

UPPER

Terminal Form

NO LEAD

Peak Reflow Temperature (Cel)

240

Number of Functions

4

Supply Voltage

15V

Reach Compliance Code

not_compliant

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Output

SEPARATE OUTPUT

Pin Count

15

JESD-30 Code

R-XUUC-N15

Qualification Status

Not Qualified

Power Supplies

+-15V

Number of Channels

1

Number of Circuits

4

Voltage - Supply, Single/Dual (±)

10V~30V ±4.5V~20V

Neg Supply Voltage-Nom (Vsup)

-15V

On-State Resistance (Max)

50Ohm

Multiplexer/Demultiplexer Circuit

1:1

Off-state Isolation-Nom

72 dB

Current - Leakage (IS(off)) (Max)

1nA

Channel Capacitance (CS(off), CD(off))

10pF 10pF

On-state Resistance Match-Nom

0.9Ohm

Switch Circuit

SPST - NC

Switch Time (Ton, Toff) (Max)

120ns, 75ns

Charge Injection

10pC

Channel-to-Channel Matching (ΔRon)

1.5 Ω (Typ)

Crosstalk

-86dB @ 100kHz

Switching

BREAK-BEFORE-MAKE

Switch-on Time-Max

120ns

Switch-off Time-Max

75ns

Normal Position

NC

RoHS Status

ROHS3 Compliant
