Lifecycle Status

OBSOLETE (Last Updated: 2 days ago)

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

16-DIP (0.300, 7.62mm)

Number of Pins

16

Weight

1.627801g

Operating Temperature

0°C~70°C TA

Packaging

Tube

Series

SWITCHMODE™

Published

2005

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

16

ECCN Code

EAR99

Terminal Finish

Tin (Sn)

Max Power Dissipation

1W

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

260

Frequency

40kHz

Time@Peak Reflow Temperature-Max (s)

40

Base Part Number

TL494

Function

Step-Down, Step-Up/Step-Down

Number of Outputs

2

Output Voltage

30V

Output Type

Transistor Driver

Operating Supply Voltage

15V

Input Voltage-Nom

15V

Analog IC - Other Type

SWITCHING CONTROLLER

Output Configuration

Positive

Power Dissipation

1W

Output Current

200mA

Voltage - Supply (Vcc/Vdd)

7V~40V

Max Supply Current

15mA

Control Features

Dead Time Control, Frequency Control

Topology

Buck, Push-Pull

Control Mode

VOLTAGE-MODE

Common Mode Rejection Ratio

90 dB

Frequency - Switching

200kHz

Control Technique

PULSE WIDTH MODULATION

Input Offset Voltage (Vos)

2mV

Rise Time

100ns

Synchronous Rectifier

Yes

Fall Time (Typ)

40 ns

Nominal Input Voltage

40V

Max Duty Cycle

48 %

Input Bias Current

-100nA

Clock Sync

No

Output Phases

1

Height

4.8768mm

Length

21.336mm

Width

7.62mm

REACH SVHC

Unknown

RoHS Status

RoHS Compliant

Lead Free

Lead Free
