Mounting Type

Through Hole

Package / Case

SC-72

Surface Mount

NO

Number of Pins

3

Weight

453.59237mg

Transistor Element Material

SILICON

Current - Continuous Drain (Id) @ 25℃

100mA Ta

Drive Voltage (Max Rds On, Min Rds On)

1.5V 4V

Number of Elements

1

Power Dissipation (Max)

250mW Ta

Turn Off Delay Time

190 ns

Voltage - Gate Threshold (Vgs(th)) (Max) @ Id

1.3V @ 100μA

Operating Temperature

150°C TJ

Packaging

Bulk

Published

2012

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

3

ECCN Code

EAR99

Terminal Finish

Tin/Copper/Silver/Nickel (Sn/Cu/Ag/Ni)

Number of Channels

1

Element Configuration

Single

Operating Mode

ENHANCEMENT MODE

Turn On Delay Time

18 ns

FET Type

N-Channel

Transistor Application

SWITCHING

Rds On (Max) @ Id, Vgs

7.8 Ω @ 50mA, 4V

Input Capacitance (Ciss) (Max) @ Vds

6.6pF @ 10V

Gate Charge (Qg) (Max) @ Vgs

1.57nC @ 10V

Rise Time

42ns

Drain to Source Voltage (Vdss)

50V

Vgs (Max)

±10V

Fall Time (Typ)

105 ns

Continuous Drain Current (ID)

100mA

Gate to Source Voltage (Vgs)

10V

DS Breakdown Voltage-Min

50V

RoHS Status

RoHS Compliant

Lead Free

Lead Free
