Mounting Type

Surface Mount

Package / Case

6-SMD Module

Mfr

TDK-Lambda

Voltage-Output 1

12V

Standard Number

62368-1

Series

CCG1R5-10 (6W)

Packaging

Tray

Operating Temperature

-40°C ~ 95°C (With Derating)

Size / Dimension

0.75" L x 0.49" W x 0.46" H (19.0mm x 12.4mm x 11.8mm)

Part Status

Active

Type

Isolated Module

Applications

ITE (Commercial)

Power (Watts)

6 W

Number of Outputs

1

Approval Agency

IEC, UL, CSA, EN, CE, UKCA

Efficiency

89%

Voltage - Isolation

1.5 kV

Voltage - Input (Max)

18V

Voltage - Input (Min)

4.5V

Current - Output (Max)

500mA

Control Features

Enable, Active Low

Features

Adjustable Output, Remote On/Off, OCP
