Lifecycle Status

ACTIVE (Last Updated: 1 day ago)

Factory Lead Time

12 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

12-PowerWDFN

Number of Pins

12

Weight

82.3188mg

Transistor Element Material

SILICON

Number of Elements

2

Turn Off Delay Time

15 ns

Operating Temperature

-55°C~150°C TJ

Packaging

Tape & Reel (TR)

Series

PowerTrench®

Published

2017

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

12

ECCN Code

EAR99

Terminal Finish

Tin (Sn)

Max Power Dissipation

1W

Terminal Form

NO LEAD

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Reach Compliance Code

not_compliant

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Number of Channels

2

Element Configuration

Dual

Operating Mode

ENHANCEMENT MODE

Case Connection

DRAIN SOURCE

Turn On Delay Time

9.4 ns

FET Type

2 N-Channel (Dual)

Transistor Application

SWITCHING

Rds On (Max) @ Id, Vgs

19m Ω @ 7A, 10V

Vgs(th) (Max) @ Id

4V @ 250μA

Input Capacitance (Ciss) (Max) @ Vds

1070pF @ 50V

Gate Charge (Qg) (Max) @ Vgs

17nC @ 10V

Rise Time

3.2ns

Drain to Source Voltage (Vdss)

100V

Fall Time (Typ)

3.3 ns

Continuous Drain Current (ID)

7A

Gate to Source Voltage (Vgs)

20V

Drain Current-Max (Abs) (ID)

7A

Drain-source On Resistance-Max

0.019Ohm

Drain to Source Breakdown Voltage

100V

FET Technology

METAL-OXIDE SEMICONDUCTOR

FET Feature

Standard

Feedback Cap-Max (Crss)

15 pF

RoHS Status

ROHS3 Compliant
