Factory Lead Time

11 Weeks

Mounting Type

Chassis Mount

Surface Mount

NO

Operating Temperature

0°C~70°C

Series

CSS65 (65W)

Published

2013

Size / Dimension

4.00Lx2.00W x 1.18 H 101.6mmx50.8mmx30.0mm

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

7

Type

Open Frame

Applications

Medical

Power (Watts)

65W

Additional Feature

REMOTE SHUTDOWN

Terminal Position

UNSPECIFIED

Terminal Form

UNSPECIFIED

Number of Functions

1

Reach Compliance Code

compliant

JESD-30 Code

R-XXMA-X7

Number of Outputs

1

Approval Agency

CE, CSA, EN, IEC, UL

Efficiency

86%

Voltage - Isolation

4kV

Input Voltage-Nom

115V

Trim/Adjustable Output

NO

Current - Output (Max)

3.43A

Voltage - Output

19V

Protections

OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE

Total Power Output-Max

65W

Minimum Load Required

No

Features

DC Input Capable, Remote Sense, Universal Input

Height

27.5mm

Width

50.8mm
