Factory Lead Time

18 Weeks

Mount

Chassis Mount, Panel

Mounting Type

Chassis Mount

Number of Pins

12

Weight

249.999986g

Power - Output (Max)

60W

Operating Temperature

0°C~70°C With Derating

Series

SC60 (60W)

Published

2004

Size / Dimension

5.00Lx3.00W x 1.34 H 127.0mmx76.2mmx34.0mm

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

Not Applicable

Type

Open Frame

Applications

ITE (Commercial)

Power Rating

60W

Max Power Dissipation

60W

Depth

76.2mm

Number of Outputs

3

Approval Agency

CE

Efficiency

70%

Current - Output (Max)

1.5A

Current - Output

7A

Output Power

60W

Voltage - Output

5V

Protections

OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE

Voltage - Output 2

24V

Min Input Voltage

85V

Max Input Voltage

265V

Current - Output 1

7A

Voltage - Output 3

12V

Minimum Load Required

Yes

Current - Output 2

1.5A

Min Input Voltage (AC)

85V

Max Input Voltage (AC)

265V

Current - Output 3

700mA

Features

Adjustable Output, Universal Input

Height

34mm

REACH SVHC

Unknown

Radiation Hardening

No

RoHS Status

RoHS Compliant
