Factory Lead Time

8 Weeks

Mounting Type

Through Hole

Package / Case

DO-204AL, DO-41, Axial

Surface Mount

NO

Number of Pins

2

Diode Element Material

SILICON

Number of Elements

1

Packaging

Tape & Reel (TR)

Published

2007

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

ECCN Code

EAR99

Terminal Finish

Matte Tin (Sn)

HTS Code

8541.10.00.70

Terminal Form

WIRE

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

R2000

JESD-30 Code

O-PALF-W2

Qualification Status

Not Qualified

Configuration

SINGLE

Speed

Standard Recovery >500ns, > 200mA (Io)

Diode Type

Standard

Current - Reverse Leakage @ Vr

5μA @ 2000V

Voltage - Forward (Vf) (Max) @ If

3V @ 500mA

Case Connection

ISOLATED

Operating Temperature - Junction

-55°C~150°C

Output Current-Max

0.5A

Voltage - DC Reverse (Vr) (Max)

2000V

Current - Average Rectified (Io)

500mA

Rep Pk Reverse Voltage-Max

2000V

Capacitance @ Vr, F

30pF @ 4V 1MHz

REACH SVHC

not_compliant

RoHS Status

RoHS Compliant
