Factory Lead Time

12 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

SOD-123H

Diode Element Material

SILICON

Number of Elements

1

Operating Temperature (Max.)

150°C

Packaging

Tape & Reel (TR)

Series

Automotive, AEC-Q101

Published

2014

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

Terminal Finish

Tin (Sn)

Additional Feature

LOW POWER LOSS

Terminal Position

DUAL

Terminal Form

FLAT

Peak Reflow Temperature (Cel)

260

Time@Peak Reflow Temperature-Max (s)

30

JESD-30 Code

R-PDSO-F2

Configuration

SINGLE

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

Schottky

Current - Reverse Leakage @ Vr

500μA @ 100V

Voltage - Forward (Vf) (Max) @ If

850mV @ 1A

Operating Temperature - Junction

-55°C~150°C

Output Current-Max

1A

Voltage - DC Reverse (Vr) (Max)

100V

Max Reverse Voltage (DC)

100V

Average Rectified Current

1A

Capacitance @ Vr, F

120pF @ 4V 1MHz

RoHS Status

ROHS3 Compliant
