Factory Lead Time

12 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

2-SMD, No Lead

Diode Element Material

SILICON

Number of Elements

1

Operating Temperature (Max.)

175°C

Packaging

Tape & Reel (TR)

Series

Automotive, AEC-Q101

Published

2014

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

Terminal Finish

Tin (Sn)

Applications

GENERAL PURPOSE

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

260

Time@Peak Reflow Temperature-Max (s)

30

JESD-30 Code

R-PDSO-N2

Configuration

SINGLE

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

Standard

Current - Reverse Leakage @ Vr

5μA @ 400V

Voltage - Forward (Vf) (Max) @ If

1V @ 3A

Operating Temperature - Junction

-65°C~175°C

Output Current-Max

3A

Voltage - DC Reverse (Vr) (Max)

400V

Max Reverse Voltage (DC)

400V

Average Rectified Current

3A

Number of Phases

1

Capacitance @ Vr, F

23pF @ 4V 1MHz

Non-rep Pk Forward Current-Max

100A

Reverse Current-Max

5μA

RoHS Status

ROHS3 Compliant
