Lifecycle Status

ACTIVE (Last Updated: 7 months ago)

Factory Lead Time

15 Weeks

Contact Plating

Tin

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

DO-204AH, DO-35, Axial

Number of Pins

2

Weight

4.535924g

Diode Element Material

SILICON

Breakdown Voltage / V

60V

Number of Elements

1

Packaging

Tape & Reel (TR)

JESD-609 Code

e3

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

ECCN Code

EAR99

Max Operating Temperature

200°C

Min Operating Temperature

-65°C

Additional Feature

MATCHED BATCH AVAILABLE

HTS Code

8541.10.00.70

Voltage - Rated DC

60V

Terminal Form

WIRE

Current Rating

15mA

Base Part Number

1N62

Pin Count

2

Polarity

Standard

Element Configuration

Single

Speed

Small Signal =< 200mA (Io), Any Speed

Diode Type

Schottky

Current - Reverse Leakage @ Vr

200nA @ 50V

Output Current

15mA

Voltage - Forward (Vf) (Max) @ If

1V @ 15mA

Case Connection

ISOLATED

Forward Current

15mA

Max Reverse Leakage Current

200nA

Operating Temperature - Junction

-65°C~200°C

Max Surge Current

50mA

Current - Average Rectified (Io)

15mA DC

Forward Voltage

410mV

Max Reverse Voltage (DC)

60V

Average Rectified Current

15mA

Peak Reverse Current

200nA

Max Repetitive Reverse Voltage (Vrrm)

60V

Capacitance @ Vr, F

2.2pF @ 0V 1MHz

Peak Non-Repetitive Surge Current

50mA

Max Forward Surge Current (Ifsm)

50mA

Diameter

2mm

Height

2mm

Length

4.5mm

Width

2mm

REACH SVHC

No SVHC

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
