Lifecycle Status

ACTIVE (Last Updated: 6 months ago)

Factory Lead Time

14 Weeks

Mounting Type

Through Hole

Package / Case

TO-220-2

Surface Mount

NO

Number of Elements

1

Operating Temperature (Max.)

175°C

Packaging

Tube

Series

ECOPACK®2

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

Applications

HIGH VOLTAGE POWER

Terminal Position

SINGLE

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

STPSC2

JESD-30 Code

R-PSFM-T2

Configuration

SINGLE

Speed

No Recovery Time > 500mA (Io)

Diode Type

Silicon Carbide Schottky

Current - Reverse Leakage @ Vr

12μA @ 1200V

Voltage - Forward (Vf) (Max) @ If

1.5V @ 2A

Case Connection

CATHODE

Forward Current

2A

Operating Temperature - Junction

-40°C~175°C

Output Current-Max

5A

Voltage - DC Reverse (Vr) (Max)

1200V

Number of Phases

1

Reverse Recovery Time

0ns

Rep Pk Reverse Voltage-Max

1200V

JEDEC-95 Code

TO-220AC

Capacitance @ Vr, F

190pF @ 0V 1MHz

Reverse Current-Max

12μA

RoHS Status

ROHS3 Compliant
