Mount

Chassis Mount

Mounting Type

Chassis Mount

Package / Case

Powertap II

Number of Pins

3

Diode Element Material

SILICON

Breakdown Voltage / V

30V

Number of Elements

2

Packaging

Tray

Series

SWITCHMODE™

Published

2004

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

ECCN Code

EAR99

Terminal Finish

Nickel (Ni)

Max Operating Temperature

150°C

Min Operating Temperature

-55°C

Additional Feature

FREE WHEELING DIODE, UL RECOGNIZED

HTS Code

8541.10.00.80

Voltage - Rated DC

30V

Terminal Position

UPPER

Terminal Form

UNSPECIFIED

Peak Reflow Temperature (Cel)

260

Reach Compliance Code

not_compliant

Current Rating

200A

Time@Peak Reflow Temperature-Max (s)

40

Pin Count

2

JESD-30 Code

R-PUFM-X2

Qualification Status

Not Qualified

Element Configuration

Common Cathode

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

Schottky

Current - Reverse Leakage @ Vr

5mA @ 30V

Voltage - Forward (Vf) (Max) @ If

600mV @ 200A

Max Reverse Leakage Current

5mA

Max Surge Current

1.5kA

Max Reverse Voltage (DC)

30V

Average Rectified Current

100A

Number of Phases

1

Non-rep Pk Forward Current-Max

1500A

Diode Configuration

1 Pair Common Cathode

RoHS Status

Non-RoHS Compliant

Lead Free

Contains Lead
