Lifecycle Status

ACTIVE (Last Updated: 6 months ago)

Factory Lead Time

15 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

TO-220-3

Number of Pins

3

Weight

2.299997g

Diode Element Material

SILICON

Number of Elements

2

Packaging

Tube

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

3

ECCN Code

EAR99

Max Operating Temperature

175°C

Min Operating Temperature

-65°C

Applications

GENERAL PURPOSE

Terminal Position

SINGLE

Base Part Number

FERD60

Element Configuration

Common Cathode

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

FERD (Field Effect Rectifier Diode)

Current - Reverse Leakage @ Vr

1500μA @ 45V

Voltage - Forward (Vf) (Max) @ If

500mV @ 30A

Forward Current

60A

Operating Temperature - Junction

175°C Max

Max Surge Current

300A

Forward Voltage

510mV

Max Reverse Voltage (DC)

45V

Average Rectified Current

30A

Number of Phases

1

Peak Reverse Current

50mA

Max Repetitive Reverse Voltage (Vrrm)

45V

JEDEC-95 Code

TO-220AB

Peak Non-Repetitive Surge Current

300A

Diode Configuration

1 Pair Common Cathode

Reverse Voltage (DC)

45V

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
