Factory Lead Time

18 Weeks

Mount

Chassis Mount, Panel, Screw

Mounting Type

Chassis Mount

Package / Case

Y2-DCB

Number of Pins

3

Diode Element Material

SILICON

Number of Elements

2

Packaging

Bulk

Published

2004

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

3

ECCN Code

EAR99

Max Operating Temperature

150°C

Min Operating Temperature

-40°C

Applications

HIGH POWER

Additional Feature

UL RECOGNIZED

HTS Code

8541.10.00.80

Terminal Position

UPPER

Terminal Form

UNSPECIFIED

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

MDD220

Qualification Status

Not Qualified

Speed

Standard Recovery >500ns, > 200mA (Io)

Diode Type

Standard

Current - Reverse Leakage @ Vr

40mA @ 1200V

Voltage - Forward (Vf) (Max) @ If

1.4V @ 600A

Case Connection

ISOLATED

Forward Current

450A

Voltage - DC Reverse (Vr) (Max)

1200V

Forward Voltage

1.4V

Max Reverse Voltage (DC)

1.2kV

Average Rectified Current

270A

Number of Phases

1

Peak Reverse Current

40mA

Max Repetitive Reverse Voltage (Vrrm)

1.2kV

Peak Non-Repetitive Surge Current

9kA

Reverse Voltage

1.2kV

Diode Configuration

1 Pair Series Connection

Height

32mm

Length

116mm

Width

60mm

REACH SVHC

No SVHC

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
