Factory Lead Time

10 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

SOD-123T

Diode Element Material

SILICON

Number of Elements

1

Operating Temperature (Max.)

125°C

Packaging

Tape & Reel (TR)

Published

2012

JESD-609 Code

e3

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

ECCN Code

EAR99

Terminal Finish

Tin (Sn)

Additional Feature

LOW POWER LOSS

HTS Code

8541.10.00.80

Terminal Position

DUAL

Terminal Form

FLAT

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

CDBM140

JESD-30 Code

R-PDSO-F2

Configuration

SINGLE

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

Schottky

Current - Reverse Leakage @ Vr

500μA @ 40V

Voltage - Forward (Vf) (Max) @ If

500mV @ 1A

Max Reverse Leakage Current

500μA

Operating Temperature - Junction

-50°C~125°C

Max Surge Current

30A

Output Current-Max

1A

Max Reverse Voltage (DC)

40V

Average Rectified Current

1A

Capacitance @ Vr, F

120pF @ 4V 1MHz

REACH SVHC

not_compliant

RoHS Status

ROHS3 Compliant
