Factory Lead Time

8 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

2-SMD, No Lead

Diode Element Material

SILICON

Number of Elements

1

Operating Temperature (Max.)

125°C

Packaging

Tape & Reel (TR)

Published

2003

JESD-609 Code

e4

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

ECCN Code

EAR99

Terminal Finish

Gold (Au)

Additional Feature

HIGH RELIABILITY

HTS Code

8541.10.00.70

Capacitance

3pF

Voltage - Rated DC

80V

Max Power Dissipation

150mW

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

260

Current Rating

100mA

Time@Peak Reflow Temperature-Max (s)

30

Base Part Number

CDSU101

JESD-30 Code

R-PDSO-N2

Configuration

SINGLE

Speed

Small Signal =< 200mA (Io), Any Speed

Diode Type

Standard

Current - Reverse Leakage @ Vr

50nA @ 75V

Voltage - Forward (Vf) (Max) @ If

1V @ 100mA

Current - Output

100mA

Forward Current

100mA

Operating Temperature - Junction

125°C Max

Max Surge Current

1A

Max Reverse Voltage (DC)

80V

Average Rectified Current

100mA

Reverse Recovery Time

4 ns

Peak Reverse Current

50nA

Capacitance @ Vr, F

3pF @ 0.5V 1MHz

Recovery Time

4 ns

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
