Factory Lead Time

22 Weeks

Mount

Chassis Mount, Screw

Mounting Type

Chassis Mount

Package / Case

M2

Number of Pins

5

Diode Element Material

SILICON

Number of Elements

1

Operating Temperature

-40°C~150°C TJ

Packaging

Bulk

Published

2009

JESD-609 Code

e0

Pbfree Code

no

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

5

ECCN Code

EAR99

Terminal Finish

TIN LEAD

Terminal Position

UPPER

Terminal Form

UNSPECIFIED

Pin Count

5

Element Configuration

Single

Diode Type

Three Phase

Current - Reverse Leakage @ Vr

300μA @ 1600V

Voltage - Forward (Vf) (Max) @ If

1.6V @ 150A

Case Connection

ISOLATED

Forward Current

75A

Max Surge Current

750A

Forward Voltage

1.15V

Number of Phases

3

Peak Reverse Current

300μA

Max Repetitive Reverse Voltage (Vrrm)

1.6kV

Peak Non-Repetitive Surge Current

750A

Reverse Voltage (DC)

1.7kV

Height

30mm

Length

72mm

Width

42mm

Radiation Hardening

No

RoHS Status

RoHS Compliant
