Factory Lead Time

12 Weeks

Mounting Type

QC Terminal

Package / Case

5-Square, SCVB

Surface Mount

NO

Diode Element Material

SILICON

Number of Elements

6

Operating Temperature

-55°C~150°C TJ

Packaging

Tray

Published

2008

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

5

ECCN Code

EAR99

Additional Feature

UL RECOGNIZED

HTS Code

8541.10.00.80

Terminal Position

UPPER

Terminal Form

SOLDER LUG

Peak Reflow Temperature (Cel)

260

Time@Peak Reflow Temperature-Max (s)

30

JESD-30 Code

S-XUFM-D5

Configuration

BRIDGE, 6 ELEMENTS

Diode Type

Three Phase

Current - Reverse Leakage @ Vr

100μA @ 1600V

Voltage - Forward (Vf) (Max) @ If

1.1V @ 12.5A

Case Connection

ISOLATED

Max Reverse Leakage Current

100μA

Max Surge Current

350A

Output Current-Max

35A

Current - Average Rectified (Io)

35A

Number of Phases

3

Voltage - Peak Reverse (Max)

1.6kV

RoHS Status

ROHS3 Compliant
