Lifecycle Status

ACTIVE (Last Updated: 22 hours ago)

Factory Lead Time

13 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

4-EDIP (0.300, 7.62mm)

Number of Pins

4

Supplier Device Package

4-DIP

Weight

640mg

Number of Elements

1

Voltage Rated

25V

Operating Temperature

-55°C~150°C TJ

Packaging

Tube

Published

2011

Tolerance

10%

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Max Operating Temperature

150°C

Min Operating Temperature

-55°C

Capacitance

47nF

Voltage - Rated DC

200V

Max Power Dissipation

3.1W

Current Rating

1.5A

Base Part Number

DF02

Case Code (Metric)

2012

Case Code (Imperial)

0805

Element Configuration

Single

Diode Type

Single Phase

Current - Reverse Leakage @ Vr

5μA @ 200V

Output Current

1.5A

Voltage - Forward (Vf) (Max) @ If

1.1V @ 1A

Forward Current

1.5A

Max Surge Current

50A

Current - Average Rectified (Io)

1.5A

Forward Voltage

1.1V

Average Rectified Current

1A

Peak Reverse Current

5μA

Max Repetitive Reverse Voltage (Vrrm)

200V

Peak Non-Repetitive Surge Current

50A

Max Forward Surge Current (Ifsm)

50A

Voltage - Peak Reverse (Max)

200V

Reverse Voltage (DC)

140V

Height

3.3mm

Length

8.51mm

Width

6.48mm

Thickness

939.8μm

REACH SVHC

No SVHC

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
