Factory Lead Time

13 Weeks

Lifecycle Status

ACTIVE (Last Updated: 19 hours ago)

Package / Case

4-SMD, Gull Wing

Mounting Type

Surface Mount

Mount

Through Hole

Number of Pins

4

Supplier Device Package

4-SDIP

Weight

484mg

Voltage Rated

100V

Number of Elements

1

Published

2011

Packaging

Tape & Reel (TR)

Operating Temperature

-55°C~150°C TJ

Tolerance

10%

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Max Operating Temperature

150°C

Min Operating Temperature

-55°C

Capacitance

4.7pF

Voltage - Rated DC

50V

Max Power Dissipation

3.1W

Current Rating

1.5A

Base Part Number

DF005

Case Code (Metric)

2012

Case Code (Imperial)

0805

Element Configuration

Single

Diode Type

Single Phase

Current - Reverse Leakage @ Vr

5μA @ 50V

Power Dissipation

3.1W

Output Current

1.5A

Voltage - Forward (Vf) (Max) @ If

1.1V @ 1A

Forward Current

1.5A

Max Reverse Leakage Current

50μA

Max Surge Current

50A

Current - Average Rectified (Io)

1.5A

Forward Voltage

1.1V

Average Rectified Current

1.5A

Peak Reverse Current

5μA

Max Repetitive Reverse Voltage (Vrrm)

50V

Peak Non-Repetitive Surge Current

50A

Max Forward Surge Current (Ifsm)

50A

Voltage - Peak Reverse (Max)

50V

Width

6.5mm

Length

1.6002mm

Height

3.3mm

Thickness

889μm

REACH SVHC

No SVHC

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
