Factory Lead Time

12 Weeks

Mounting Type

Surface Mount

Package / Case

4-SMD, Gull Wing

Surface Mount

YES

Diode Element Material

SILICON

Number of Elements

4

Operating Temperature

-55°C~150°C TJ

Packaging

Cut Tape (CT)

Published

2005

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

4

ECCN Code

EAR99

Terminal Finish

Matte Tin (Sn)

HTS Code

8541.10.00.70

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Reach Compliance Code

not_compliant

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

LMB10

Pin Count

4

JESD-30 Code

R-PDSO-G4

Qualification Status

Not Qualified

Configuration

BRIDGE, 4 ELEMENTS

Diode Type

Single Phase

Current - Reverse Leakage @ Vr

5μA @ 1000V

Voltage - Forward (Vf) (Max) @ If

950mV @ 400mA

Output Current-Max

0.8A

Current - Average Rectified (Io)

1A

Number of Phases

1

Non-rep Pk Forward Current-Max

30A

Voltage - Peak Reverse (Max)

1kV

Breakdown Voltage-Min

1000V

RoHS Status

ROHS3 Compliant
