Factory Lead Time

20 Weeks

Mounting Type

Surface Mount, Right Angle

Housing Material

Liquid Crystal Polymer (LCP), Glass Filled

Actuator Material

Polyamide (PA), Nylon, Glass Filled

Contact Materials

Copper Alloy

Voltage Rated

50V

Operating Temperature

-25°C~85°C

Packaging

Cut Tape (CT)

Series

Easy-On 501628

Published

2009

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Solder

Number of Positions

45

Number of Rows

1

Gender

FEMALE

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Filter Feature

NO

Mixed Contacts

NO

Option

GENERAL PURPOSE

Current Rating (Amps)

0.2A

Pitch

0.012 0.30mm

Total Number of Contacts

45

Reach Compliance Code

compliant

Contact Finish

Gold

UL Flammability Code

94V-0

Mating Cycles

10

Flat Flex Type

FPC

Cable End Type

Tabbed

Locking Feature

Flip Lock

Height Above Board

0.035 0.88mm

FFC, FCB Thickness

0.20mm

Material Flammability Rating

UL94 V-0

RoHS Status

RoHS Compliant
