Factory Lead Time

9 Weeks

Mounting Type

Panel Mount

Mounting Feature

Bulkhead

Dielectric Material

Polytetrafluoroethylene (PTFE)

Body Material

Brass

Center Contact Plating

Gold

Center Contact Material

Beryllium Copper

Panel Mount

YES

Frequency(Max)

500MHz

Insulation Materials

PERFLUOROALKOXY/POLYTETRAFLUORO ETHYLENE

Operating Frequency (Max)

4GHz

Packaging

Bulk

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

ECCN Code

EAR99

Additional Feature

APPLICABLE CABLES: RG 161/U; RG 174, CAPTIVE CONTACT, INSERTION LOSS MAX AT 1.5 GHZ

HTS Code

8536.69.40.10

Fastening Type

Bayonet Lock, Threaded

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Filter Feature

NO

Option

GENERAL PURPOSE

Style

Straight

Termination Type

CRIMP

Coupling Type

SNAP

Impedance

Non-Constant

Includes

3 pcs - 1 Connector, 1 Nut, 1 Washer

Insertion Loss

0.6 dB

Body Finish

Nickel

Convert From (Adapter End)

TRS Twinaxial/Triaxial Jack, Female Socket

Convert To (Adapter End)

SMP Plug, Male Pin

VSWR

1.51

Conversion Type

Between Series

Adapter Type

Plug to Jack

Center Gender

Female to Male

Adapter Series

SMP to TRS

Features

Full Detent

RoHS Status

RoHS Compliant
