Mount

Bulkhead, Panel, Rear Side Nut

Mounting Type

Panel Mount

Package / Case

Metal

Mounting Feature

Bulkhead - Rear Side Nut

Shell Material

Copper Zinc Alloy

Contact Finish Mating

GOLD

Contact Materials

COPPER ALLOY

Shell Sizes

23

Operating Temperature

-40°C~115°C

Packaging

Bulk

Series

Han® R23

JESD-609 Code

e4

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Connector Type

Insert Shell

Fastening Type

Threaded

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Filter Feature

NO

Mixed Contacts

NO

Option

GENERAL PURPOSE

Total Number of Contacts

17

Orientation

Straight

Shielding

Unshielded

Ingress Protection

IP67 - Dust Tight, Waterproof

Shell Finish

Nickel

Housing Color

Silver

Empty Shell

YES

Backshell Type

SOLID

Note

Contacts Not Included; Insert Not Included

Environmental Characteristics

CORROSION RESISTANT

Contact Finish Termination

GOLD

Material Flammability Rating

UL94 V-0

RoHS Status

RoHS Compliant

Ratings

Dust Tight, IP67, Waterproof
