Mount

Through Hole

Mounting Type

Through Hole

Package / Case

TO-262-3 Short Leads, I2Pak

Number of Pins

3

Number of Elements

1

Operating Temperature

-30°C~125°C TJ

Packaging

Tube

JESD-609 Code

e3

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

3

Terminal Finish

Matte Tin (Sn) - annealed

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Reach Compliance Code

not_compliant

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

ACST6

Pin Count

3

Number of Outputs

1

Qualification Status

Not Qualified

Output Voltage

700V

Configuration

Single

Case Connection

MAIN TERMINAL 2

RMS Current (Irms)

6A

Hold Current

25mA

Trigger Device Type

SNUBBERLESS TRIAC

Voltage - Gate Trigger (Vgt) (Max)

1.5V

Current - Non Rep. Surge 50, 60Hz (Itsm)

45A 50A

Current - Gate Trigger (Igt) (Max)

10mA

Current - On State (It (RMS)) (Max)

6A

Leakage Current (Max)

0.5mA

Critical Rate of Rise of Off-State Voltage-Min

200V/us

Triac Type

Logic - Sensitive Gate

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
