Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

208-PBGA

Number of Pins

208

Data Converters

A/D 32x10b

Number of I/Os

143

Watchdog Timers

Yes

Operating Temperature

-40°C~125°C TA

Packaging

Tray

Series

ST10

JESD-609 Code

e2

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

208

ECCN Code

3A001.A.3

Terminal Finish

Tin/Silver (Sn/Ag)

Terminal Position

BOTTOM

Terminal Form

BALL

Peak Reflow Temperature (Cel)

260

Supply Voltage

5V

Terminal Pitch

1.27mm

Frequency

64MHz

Base Part Number

ST10F

Pin Count

208

Operating Supply Voltage

5V

Power Supplies

5V

Interface

CAN, EBI/EMI, I2C, UART, USART

Memory Size

832kB

Oscillator Type

Internal

RAM Size

68K x 8

Voltage - Supply (Vcc/Vdd)

4.5V~5.5V

uPs/uCs/Peripheral ICs Type

MICROCONTROLLER

Peripherals

POR, PWM, WDT

Program Memory Type

FLASH

Core Size

16-Bit

Program Memory Size

832KB 832K x 8

Connectivity

ASC, CANbus, EBI/EMI, I2C, SSC, UART/USART

Supply Current-Max

148mA

Bit Size

16

Has ADC

YES

DMA Channels

NO

Data Bus Width

16b

PWM Channels

YES

DAC Channels

NO

Number of Timers/Counters

5

Length

23mm

Height Seated (Max)

1.96mm

Radiation Hardening

No

RoHS Status

ROHS3 Compliant
