Factory Lead Time

12 Weeks

Mount

PCB, Through Hole

Mounting Type

Through Hole, Right Angle

Housing Material

Polybutylene Terephthalate (PBT)

Body Material

Brass

Contact Material - Plating

Silver

Contact Finish Mating

NOT SPECIFIED

Contact Materials

Copper Alloy

Voltage Rated

250V

Packaging

Bulk

Series

35

Published

1998

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Number of Terminations

3

Termination

Solder Eyelet(s)

ECCN Code

EAR99

Connector Type

Phone Jack

Resistance

20mOhm

Max Operating Temperature

65°C

Min Operating Temperature

-20°C

Color

Black

Gender

Female

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Orientation

Right Angle

Shielding

Unshielded

Depth

18.5mm

Number of Contacts

2

Number of Ports

1

Cable Length

14mm

Number of Poles

2

Number of Positions/Contacts

2 Conductors, 3 Contacts

Internal Switch(s)

Single Switch

Body Color

Silver, Black

Industry Recognized Mating Diameter

3.50mm (0.141, 1/8, Mini Plug) - Headphone

Actual Diameter

0.142 (3.60mm)

Signal Lines

Mono

Features

Thread Lock

Height

11.4mm

Length

7.5mm

REACH SVHC

Unknown

RoHS Status

ROHS3 Compliant

Flammability Rating

UL94 V-1

Lead Free

Lead Free
