Factory Lead Time

12 Weeks

Mount

Cable, Free Hanging

Mounting Type

Free Hanging (In-Line)

Number of Pins

1

Housing Material

Ethyl Cellulose

Body Material

Brass

Contact Material - Plating

Tin

Contact Finish Mating

NOT SPECIFIED

Contact Materials

Copper Alloy

Packaging

Bulk

Series

TWIN-PLUG®

JESD-609 Code

e3

Part Status

Active

Number of Terminations

6

Termination

Screw

Connector Type

Phone Plug, Twin

Color

Black

Gender

Male

Additional Feature

POLARIZED

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Orientation

Straight

Shielding

Unshielded

Number of Ports

2

Number of Poles

6

Cable Opening

0.313 (7.95mm)

Number of Positions/Contacts

2 Sets of 3 Conductors, 6 Contacts

Includes

10 pcs - 2 Connectors, 2 pc Handle, 3 Nuts, 3 Screws

Internal Switch(s)

Does Not Contain Switch

Industry Recognized Mating Diameter

6.35mm (0.250, 1/4) - Headphone

Actual Diameter

0.250 (6.35mm)

Signal Lines

Stereo (3 Conductor, TRS)

Mating Length/Depth

1.000 25.40mm 0.203 5.16mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
